Load capacity 载荷特性

m		2.5~14.8	17	20	23	25	27	30	35	40	45	50	55	60
T	a=4	10	8.5	7.03	5.96	5.4	4.92	4.33	3.57	3.0	2.57	2.22	1.94	1.7
	a=2	5						4.43	3.67	3.1	2.67	2.32	2.04	1.8

m		2.5~15.6	17	20	23	25	28	30	35	40	45	50	55
T	a=4	10	9.04	7.49	6.36	5.77	5.03	4.63	3.83	3.23	2.77	2.4	2.1
	a=2	5						4.73	3.93	3.33	2.87	2.5	2.2

m		2.5~16.5	18	20	23	25	27	30	35	40	45	50
T	a=4	10	9.04	8.0	6.8	6.17	5.63	4.97	4.11	3.48	2.99	2.6
	a=2	5							4.21	3.58	3.09	2.7

m		2.5~16.9	20	23	25	27	30	33	35	40	45
T	a=4	10	8.26	7.02	6.37	5.82	5.13	4.57	4.26	3.6	3.1
	a=2	5						4.67	4.36	3.7	3.2

m		2.5~17.3	20	23	25	27	30	32	35	40
T	a=4	10	8.45	7.19	6.52	5.96	5.26	4.87	4.37	3.7
	a=2	5							4.47	3.8



Foundation+ 1st mast
JIB		60m	60m	60m
MAST heights	0	0.32	1.17	2.17
	1	2.82	3.67	4.67
	2	5.32	6.17	7.17
	3	7.82	8.67	9.67
	4	10.32	11.17	12.17
	5	12.82	13.67	14.67
	6	15.32	16.17	17.17
	7	17.82	18.67	19.67
	8	20.32	21.17	22.17
	9	22.82	23.67	24.67
	10	25.32	26.17	27.17
	11	27.82	28.67	29.67
	12	30.32	31.17	32.17
	13	32.82	33.67	34.67
	14	35.32	36.17	37.17
	15	37.82	38.67	3.67
	16	40.32	41.17	42.17
	17	42.82	43.67	44.67
	18	45.32	46.17	47.17
